Product Description
Product Description
We have our own mould production line to tailor-make any size according to our customers' drawings.
As for cemented carbide brazed tips the features for your reference.
1) Full range of types available, more convenient for you to purchase;
2) Various grades available, therefore can provide full machining solutions;
3) Produced with precision molds, the products have better dimensional accuracy and uniform;
4) Careful surface treatment, ensuring perfect appearance, increasing customer satisfaction;
5) Made of top-quality raw material, have more stable properties, therefore easier to braze, also extend its service time.
The application range of cemented carbide brazed tips:
Mainly used for making brazed tools for metal processing. Our tips was done by HIP sintering, it provide extra 30% on bending strength compare to normal quality, which means our tips will be strong enough when meet heavy impact. Also, it will have longer tool life (better wear resistance) for you to use our tips.
*Sinter-HIP is a method of thermal consolidation for cemented carbide wherein the simultaneous application of heat and pressure fully consolidates the carbide during the sintering process.
It is very important to select the right grade to match the using purpose, need to find the perfect balance between hardness and bending strength, so we have to consider the physical properties of the processing object, also the working condition for tools, like running speed, impact.
Grade and Specification
| ISO Grade | Co% | Density(g/cm³) | Hardness HRA (ISO3738) | Bending Strength (N/mm2) | Grain Size(μm) | Suitable for |
| K01 | 3 | 15 | 94.2 | 2750 | 0.6 | Shaving board, density board, brass & aluminum alloy |
| K05 | 6 | 14.9 | 93.3 | 3200 | 0.6 | Solid hard wood, plywood boar, MDF |
| K10 | 6 | 14.8 | 92 | 3200 | 0.8 | Hard wood(excelent performance grade) |
| K20 | 7 | 14.9 | 91 | 2600 | 1.2 | Ordinary wood and plasticmaterial |
| K30 | 8 | 14.8 | 90 | 2700 | 1.2 | For ordinary aluminum |
| M30 | 12 | 13 | 91 | 2400 | 0.8 | For angle steel, stainless steel and normal steel, like C45 |
| M40 | 12 | 13 | 90 | 2400 | 1.4 | Metallurgical saw blade only |
Product Show
Workshop Information
Packing:
Related product:
FAQ:
Q. Are you manufacturer or trading company ?
A. We are the manufacturer with our own workshop and production teams.
Q. How to ensure the good quality from you?
A: All product will go through inspection at least by 3 times:
Material checking: Use the same batch of material, to make carbide pieces to test the compositions and mechanical properties, like density, hardness, bending strength, Cobalt Magnetism, etc.
Semi product checking: Main checking
Final product checking: Check all data and compare to the target sample we made.
Also check all dimensions and surface finishing.
Q:Is your product customized or standard?
A: We have the regular product and also have rich experience for customized parts.
We have many success projects that make the product based on your own designs.
