Cold Heading Dies for Different Screw Multi Stroke Die Tungsten Carbide Cold Heading Die for Oil&Gas

Get top-quality Tungsten Carbide Cold Heading Dies for different screw multi stroke die applications from our factory. Perfect for oil & gas industries.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Zonco-11418
OEM
Available
Transport Package
Carton or Wooden Case. Also Can Be Customized as P
Origin
China Zhuzhou

Product Description

Product Description:

Cold Heading Dies for Different Screw Multi Stroke Die Tungsten Carbide Cold Heading Die for Oil&Gas
Specification:

item
value
Place of Origin
China

Zhuzhou
Brand Name
Zonco
Model Number
Customized
Shaping Mode
Forging Mould
Product Material
Tungsten carbide
Product
Industrial Product
Color
Silver
Process
CNC
Surface treatment
Polishing
Feature
Wear-resisting
Package
Carton Package
Certification
ISO9001:2015
Advantage
Professional Team
Quality
Hign Precision
Tolerance
0.001mm

Introudction:

      Zonco has been specialized in the cemented tungsten carbide industry more than 10 years,and able to manufacture all kinds of tungsten carbide parts and alloy wear resisting parts based on customers' drawings and material specification requirement(prodcuts inclduing AP* series,GE seriesMWD seriesQDT seriesSL series,etc.) welcome to contact us for more details.



Application fields:

Products are widely used in various wire drawing equipment. High-precision wire materials such as steel wires, tungsten wires, molybdenum wires, copper wires, and aluminum wires are broadly used in automobiles, wires and cables, radars, instruments, and electronic devices.



Advantages:

  • Professional processing equipment
  • Unique material properties
  • Advanced technology
  • Whole process quality control system

Main product series:

Carbide wire drawing mill

Carbide threading die

Carbide roll ring

Carbide and steel assembly



Common Alloy Grades, Ghysical Mechanical Properties And Recommended Application

Grade WC% Co/Ni % Physical and mechanical properties Grain size (μm) Recommended application
Density (g/cm3) TRS (N/mm2) Hardness (HRA)
ZG01 100 0 15.3-15.5 1200 95.5 0.3 Ultra-high hardness, high wear resistance, anti-corrosion, with certain anti-destructive ability
ZG04X 96 4 15.0-15.2 1600 92.8 0.8-1.0 Suitable for drawing die, non-ferrous metal wire drawing and wear-resistant parts
ZG06 94 6 14.8-15.1 2500 90.0 1.2 Good abrasion resistance, good compression resistance, suitable for wear-resistant parts that resist abrasion and high pressure.
ZG06X 94 6 14.8-15.1 2400 91.5 1.0 Superio wear resistance,good comprehensive properties,suitable for making non-standard structure components with higher wear resistance.
ZG06A 94 6 14.8-15.1 2150 92.5 0.6-0.8
ZG08 92 8 14.6-14.9 2700 89.0 1.2-1.6 Good general performance, used for general wear parts, molds, general tools, etc.
ZG10.2 90 10 14.3-14.6 3800 91.7 0.7 Good general performance, suitable for casing and oil nozzle products
ZG11 89 11 14.3-14.7 2800 88.5 1.2-1.6 Anti-wear, anti-erosion, good comprehensive mechanical strength, suitable for wear-resistant parts in the petroleum, chemical and mechanical industries.
ZG12X 88 12 14.2-14.5 3000 89.5 1.0-1.2 Anti-erosion, good comprehensive mechanical strength, suitable for impact-resistant wear-resistant parts, molds, and roller rings.
ZG15 85 15 13.8-14.2 3000 86.5 1.2-1.6
ZG15X 85 15 13.8-14.2 4500 89.0 0.7 Excellent wear resistance and toughness,it is suitable for making integral stamping dies, anti-vibration toolholders, etc.
ZG20 80 20 13.4-13.8 3100 85.0 1.0 Excellent wear resistance and toughness
ZN06 94 6 14.5-14.9 2000 90.0 1.2 Non-magnetic alloy, suitable for sealing ring, non-magnetic wear-resistant parts and corrosion-resistant parts.
ZN09 91 9 14.3-14.6 2300 89.0 1.2-1.6
ZN11 89 11 14.0-14.3 2600 88.0 1.2
Cold Heading Dies for Different Screw Multi Stroke Die Tungsten Carbide Cold Heading Die for Oil&Gas Cold Heading Dies for Different Screw Multi Stroke Die Tungsten Carbide Cold Heading Die for Oil&Gas
Cold Heading Dies for Different Screw Multi Stroke Die Tungsten Carbide Cold Heading Die for Oil&Gas
