Product Description
Carbide wire drawing dies usually refer to all kinds of carbide die for drawing metal wires, as well as wire drawing dies for drawing optical fibers. All drawing dies have a certain shape in the center, round, square, octagonal or other special shapes. When the metal is pulled through the die hole, the size becomes smaller and even the shape changes. Steel molds are sufficient when drawing soft metals (such as gold and silver). The steel molds can have multiple holes with different diameters.
Tungsten Carbide Drawing Dies' Grades and Properties:
| Grades | Density | Hardness | TRS | Grain Size |
| g/cm3 | HRA | N/mm2 | um | |
| YL10.2 | 14.5 | 92 | 2400 | 0.8 |
| YG3 | 15.3 | 90.5 | 1500 | 1.6 |
| YG6 | 14.95 | 90.5 | 1800 | 1.6 |
| YG6X | 14.95 | 91.5 | 1700 | 1 |
| YG8 | 14.8 | 89.5 | 2200 | 1.6 |
| YG11 | 14.4 | 87 | 2300 | 1.6 |
| YG15 | 14.05 | 87.5 | 2800 | 1.6 |
| YG13X | 14.3 | 89.5 | 2600 | 1 |
| YRL10 | 14.98 | 90 | 2800 | 1.2 |
Shipment: by Express/ by Air /by Sea
We can arrange shipment according to our customers' requests.
If there is any problem related to the shipping, please feel free to contact us
1. We will try our best to reply our customers' requests within 24 hours.
2. We will maintain effective and efficient communications with our customers.
3. We provide first-class quality control and after-sale services.
