Basic Info.
Model NO.
non standard
Manufacturing Technology
Computer Technology
Driving Motor Type
Hybrid
Mold Cavity Technology
EDM Milling
Milling Speed
High Speed
Parts Detection Method
Geometric Detection
After-sales Service
After Sales Service Guaranteed
Transport Package
Safe Export Packing
Specification
25*15*335
Trademark
GQ CARBIDE
Origin
Zhuzhou, Hunan, China
HS Code
82090090
Production Capacity
500tons Per Year
Product Description
Tungsten carbide plate for punching application
Plenty of grades corrsponding to different applications
| Application Code | Chemical Composition | Physical Properties of powder | Physical and mechanical properties and mirco structure as stintered | Application recommended | ||||||||
| Co | Tic/ TacNbc | WC | Hall Flow | Apparent density | Density | Hardness | Transverse rupture strength | Coercivity | Magnetic saturation | Porosity | ||
| s/25cm3 | g/cm3 | g/cm3 | HV 30 | N/mm2 | KA/m | % | ||||||
| P10 | 9.5 | 35 | 55.5 | 35 | 2.52 | 10.3 | 1525-1675 | ≥1130 | 9.2-11.5 | 8.3-9.5 | A02 B00 | For machining steel and cast steel |
| P20 | 8.2 | 14 | 77.8 | 32 | 2.83 | 11.52 | 1560-1700 | ≥1400 | 12.0-15.5 | 7.5-8.2 | A02 B00 | For machining long-chip steel, cast steel and forgeable cast iron |
| P25 | 9.5 | 21.9 | 68.6 | 35 | 2.5 | 11.42 | 1400-1550 | ≥1700 | 8.0-10.4 | 8.5-9.5 | A02 B00 | |
| P30 | 9.3 | 6.3 | 84.4 | 32 | 3.14 | 13.02 | 1370-1560 | ≥1750 | 9.5-12.5 | 8.6-9.2 | A02 B00 | |
| 10 | 20 | 70 | 33 | 3.08 | 12.86 | 1425-1575 | ≥1600 | 13.7-15.5 | 8.1-9.1 | A02 B00 | ||
| P35 | 11 | 12 | 77 | 35 | 3.24 | 13.12 | 1320-1460 | ≥1650 | 10.7-13.1 | 9.1-10.1 | A02 B00 | For machining steel and cast steel parts with different pores including sand holes. |
| P40 | 12 | 18.93 | 69.07 | 35 | 2.88 | 12.75 | ≥1400 | ≥2250 | 15.0-19.0 | 10.0-11.2 | A04 B02 | |
| M10 | 6.1 | 16.3 | 77.6 | 35 | 3.13 | 13.3 | 1600-1800 | ≥1290 | 16.5-20.5 | 5.4-6.1 | A02 B02 | For machining steel, cast steel, manganese steel and grey cast iron. |
| M20 | 8.2 | 16.35 | 75.45 | 35 | 3.01 | 13.1 | 1530-1680 | ≥1460 | 15.0-19.0 | 7.3-8.2 | A02 B02 | For machining steel, cast steel, austenitic steel, manganese steel and grey cast iron. |
| M30 | 6 | 2 | 92 | 35 | 3.45 | 14.8 | 1450-1600 | ≥1320 | 13.5-15.1 | 5.3-6.0 | A02 B00 | Fo machining steel, cast steel, austenitic steel, grey cast iron and high temperature-resistant alloy |
| K05 | 6 | 0.3 | 93.7 | 35 | 3.45 | 14.94 | 1650-1750 | ≥1560 | 19.5-24.5 | 5.1-5.9 | A02 B02 | For machining super-hard grey cast steel, hardening steel, chilled iron, high silicon-aluminum alloy,high wear-resistant plastic, hard paper plate and ceramics. |
| 6 | 2 | 92 | 35 | 2.85 | 14.95 | 1350-1500 | ≥1600 | 21.5-26.5 | 4.9-5.9 | A02 B02 | ||
| K10-K15 | 6 | 0.4 | 93.6 | 35 | 3.45 | 14.91 | 1665-1835 | ≥123 | 19.5-24.5 | 5.2-6.2 | A02 B02 | For machining cast iron with hardness higher than 200HB, short-chip forgeable cast iron, silicon-aluminum alloy, copper alloy, plastic, glass, ceramics and stones. |
| K20 | 6 | 0.4 | 93.6 | 35 | 3.25 | 14.9 | 1600-1700 | ≥1670 | 16.3-19.2 | 5.2-6.0 | A02 B02 | For machining grey cast iron with hardness lower than 200HB, non-ferrous metal, copper, brass and aluminum |
| 7.8 | 1 | 91.2 | 35 | 3.35 | 14.61 | ≥1400 | ≥2000 | 15.0-18.0 | 6.6-7.8 | A02 B02 | ||
| K30 | 6 | 2 | 92 | 35 | 3.45 | 14.8 | 1450-1600 | ≥1320 | 13.5-15.1 | 5.3-6.0 | A02 B00 | For machining low-hardness grey cast iron, low-strength steel and compact wood. |
| G05 | 6 | 94 | 35 | 3.45 | 14.9 | 1370-1490 | ≥2300 | 11.3-12.6 | 5.5-5.9 | A02 B00 | For drilling soft or medium hard rock formation with a single-zxis compression strength less than 60 Mpa | |
| 7.5 | 92.5 | 35 | 3.45 | 14.78 | 1300-1500 | ≥2600 | 9.4-12.5 | 6.6-7.5 | A02 B00 | |||
| G10 | 8.3 | 91.7 | 36 | 3.4 | 14.65 | ≥1500 | ≥2000 | 7.6-9.6 | 7.1-8.2 | A02 B02 | For drilling soft or medium hard rock formation with a single-zxis compression strength of60-120 Mpa | |
| 9.5 | 90.5 | 36 | 3.55 | 14.52 | 1155-1275 | ≥2400 | 6.6-7.4 | 8.6-9.5 | A02 B02 | |||
| G20 | 10 | 0.5 | 89.5 | 35 | 3.39 | 14.51 | ≥1100 | ≥2550 | 6.0-8.0 | 8.8-9.8 | A02 B02 | For drilling soft or medium hard rock formation with a single-zxis compression strength of 120-200 Mpa |
| 11.5 | 88.5 | 36 | 3.4 | 14.3 | ≥1050 | ≥2400 | 6.0-8.0 | 9.5-11.4 | A02 B00 | |||
| G30 | 13 | 87 | 35 | 3.35 | 14.22 | ≥980 | ≥2500 | 5.5-7.0 | 11.7-13.0 | A02 B02 | For drilling soft or medium hard rock formation with a single-zxis compression strength of 120-200 Mpa | |
| 11 | 89 | 36 | 3.45 | 14.39 | 1060-1170 | ≥2110 | 5.3-6.1 | 9.9-11.0 | A02 B02 | |||
| G40 | 15 | 85 | 37 | 3.15 | 14 | 950-1100 | ≥2160 | 4.8-6.3 | 13.5-15.0 | A02 B02 | For drilling soft or medium hard rock formation with a single-zxis compression strength of 120-200 Mpa | |
| 16.5 | 83.5 | 37 | 3.13 | 13.9 | ≥880 | ≥2640 | 4.8-6.4 | 14.1-16.4 | A02 B02 | |||
| G50 | 20 | 80 | 37 | 3.13 | 13.5 | ≥760 | ≥2480 | 3.5-4.5 | 17.0-19.8 | A02 B02 | For drilling hard or super hard rock formation with a single axis compression strength higher than 200 Mpa | |
| G60 | 25 | 75 | 39 | 3.15 | 13.12 | 830-870 | ≥2650 | 4.0-4.6 | 20.0-25 | A04 B02 | ||
| LS10 | 3 | 0.3 | 96.7 | 36 | 3.5 | 15.23 | ≥1600 | ≥1300 | 21.0-30.0 | 2.4-3.1 | A04 B02 | For making seal rings and dies used for drawing metal wire with diameter less than 6 mm |
| 3 | 97 | 35 | 3.6 | 15.25 | 1560-1680 | ≥1300 | 14.5-19.5 | 2.4-3.0 | A04 B02 | |||
| 4 | 2 | 94 | 35 | 3.55 | 15.02 | 1760-1940 | ≥1130 | 20.3-24.7 | 3.2-4.0 | A02 B00 | ||
| LS20 | 6 | 0.5 | 93.5 | 35 | 3.45 | 14.94 | ≥1550 | ≥1700 | 21.5-26.5 | 4.9-5.9 | A02 B02 | For making seal rings and dies used for drawing metal wire with diameter less than 20 mm and tube of diameters less than 10mm. |
| 4 | 94 | 35 | 3.55 | 14.95 | 1400-1560 | ≥1670 | 12.5-16.0 | 5.0-6.0 | A02 B02 | |||
| 4 | 94 | 35 | 3.55 | 14.95 | 1530-1630 | ≥1530 | 15.3-17.7 | 5.0-5.8 | A02 B00 | |||
| LS25 | 7.8 | 92.2 | 35 | 3.44 | 14.75 | ≥1300 | ≥1900 | 10.2-15.0 | 6.5-7.7 | A02 B02 | ||
| LS30 | 9.5 | 90 | 35 | 3.01 | 14.45 | 1550-1650 | ≥1610 | 18.9-22.0 | 8.0-9.5 | A02 B02 | For making seal rings and dies used for drawing metal wire with diameter less than 50 mm and tube of diameters less than 35mm. | |
| 10 | 90 | 37 | 3.28 | 14.55 | ≥1200 | ≥2300 | 9.0-12.0 | 9.0-10.0 | A02 B02 | |||
| 11 | 89 | 38 | 3.26 | 14.44 | ≥1100 | ≥2000 | 8.0-13.0 | 9.5-11.0 | A02 B02 | |||
| 12 | 88 | 38 | 3.25 | 14.3 | ≥1200 | ≥2500 | 7.0-11.0 | 11.0-12.0 | A02 B02 | |||
| Note: General grade 1) All data above are typical. 2) P, M, K indicate cemented carbide used for long-chip machining , long-chip or short-chip machining and short-chip machinmg respectively. 3) G indicates cemented carbide used for geology prospecting and mmmg 4) LS, LT, LQ, LV indicate cemented carbide used for drawing dies, punching dies. | ||||||||||||
