Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

Discover the advantages of our Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers. As a leading factory, we offer high performance and durable products.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • specification
  • Company Profile
  • Our Advantages
  • FAQ
Overview

Basic Info.

Model NO.
wear tube
Grade
Q235/Q345+Chrome Carbide
Delivery Time
8-14 Days
Use
Mining ;Power Utility;Steel Mill;Coal ;Cement
Transport Package
Pallet, Wooden Box
Specification
custom
Trademark
hard-plate
Origin
China
Production Capacity
6000 Tons

Product Description

Product Description

Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

Product Descripition

The surface alloy layer of this product has high hardness and excellent wear-resistant performance.The base metal is a common rolled plate with good toughness and plasticity.The wear-resistant alloy layer and the base metal are metallurgy combined and firmly combined in service,wear is resisted by the high hardness of the surface allov aver. And the impact of external force is resisted by the strength and toughness of the matrix.



Hardness:HRC58-63

Thickness:4+4,5+5,6+5,8+5,8+8,10+5,10+8,10+10...etc

Minimum Inner Diameter:80mm

Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

specification


Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

Brand Haweir

Base Plate Q235/2345
Hardfacing Layer High chromium high carbide overlay
Chemical Composition C(%):3-5 Cr(%):20-26
Hardness HRC58-63
Surface Treatment Hardfacing, clading,coated
Minimum Inner Diameter 80mm
Wear Resistance High wear resistance
Thickness 4+4,5+5,6+5,8+5,8+8,10+8,10+10...etc
Place of Origin China
Application Mining, Steel,Cement,Power,Port,etc
Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers
Company Profile

Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

Company profile



Shenyang Hard Welding Surface Engineering Co. , Ltd. is a high-tech enterprise specializing in processing and manufacturing metal matrix hardfacing wear plate and materials. Relying on the domestic institutes, has independently researched and developed the chromium carbide overlay wear plate, which reaches the international level. we can offer system solutions in metallurgy , electric power , cement , mining and other industries.

Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy LayersHard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy LayersHard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

Our Advantages

Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers

R & D    ABILITY

♦Liaoning high-tech enterprise,wear-resistant overlay welding demostration center of MIIT

♦More than 50 national patents including invention patents

♦Well-equipped laboratory with high-end metallographic analysis equipment, spark- optical emission spectrometer.Carbon sulfur analyzer,spectro-photometer,grain-abrasion testing machine,rockwel hardness apparatus,impacttesting machine

♦Participate in setting wear-resistant pipe standard for DL/T power industry

♦Member of China Welding Association

♦Industry-university-research cooperation enterprise of Liaoning petrochemical University

Hard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy LayersHard-Plate Duplex Metal Wear Resistant Steel Pipelines with Chrome Alloy Layers



FAQ



Q1: Why are there so many cracks?
A1. Due to the cooling rates of dissimilar metals. Our hard facing plate for coal chute liner is manufactured by welding which results in high temperatures. During the cooling, the plate goes through a stress relieving which is a natural process and does not effect the performance of the plate. The stress relief cracks should be between 3/4" - 2" apart. The cracks can be touched up by our chrome carbide welding rod.

Q2: What is the best method of attachment?
A2. hard facing plate for coal chute liner is usually attached by countersunk bolts, welding studs, perimeter welding, or plug welding. Some methods are better suited than others depending on the specific application. For more detail on each method see the installation section.

Q3: Can hard facing plate for coal chute liner be drilled or machined?
A3. hard facing plate for coal chute liner cannot be machined or drilled. It can however be ground. Mild steel inserts are used to create countersunk or counter bored holes. hard facing plate for coal chute liner can be cut using plasma, Grinding wheel saw, or air-arc gouging.

Q4:MOQ?
A4.Our product has no limit to quantity, it can be ordered according to customer requirement.
