Basic Info.
Product Name
Efficient Milling Cutter
Materials
Solid Carbide (Tungsten Steel)
Controlling Mode
CNC Tooling System, CNC
End Cut Type
Flat End
Features1
High Hardness
Features2
Good Wear Resistance.
Features3
High Precision
CNC or Not
CNC
Certification
GS, CE, RoHS, ISO 9001
Helix Angle
35
Workpiece Material
Die Casting Steel,General Steel, Cast Iron....
Flute
2/3/4
Machine Type
Milling Maching
Color
Black/Bronze/Blue/Golden
Diameter
1~20 mm
Transport Package
Customized
Specification
Customized
Trademark
Quander Tools
Origin
Changzhou, China
Production Capacity
50000000PCS/Month
Product Description
| Specification | Diameter D1 | Blade length L1 | Shank diameter D2 | Overall length L2 |
| D3*9*50L | 3 | 9 | / | 50 |
| D3*12*75L | 3 | 12 | / | 75 |
| D3*15*100L | 3 | 15 | / | 100 |
| Dl*3*D4*50L | 1 | 3 | 4 | 50 |
| D1.5*4.5*D4*50L | 1.5 | 4.5 | 4 | 50 |
| D2*6*D4*50L | 2 | 6 | 4 | 50 |
| D2.5*7.5*D4*50L | 2.5 | 7.5 | 4 | 50 |
| D3*9*D4*50L | 3 | 9 | 4 | 50 |
| D3.5*10*D4*50L | 3.5 | 10 | 4 | 50 |
| D4*10*50L | 4 | 10 | / | 50 |
| D4*16*75L | 4 | 16 | / | 75 |
| D4*20*100L | 4 | 20 | / | 100 |
| D5*13*50L | 5 | 13 | / | 50 |
| D5*20*75L | 5 | 20 | / | 75 |
| D5*25*100L | 5 | 20 | / | 100 |
| D5*13*D6*50L | 5 | 13 | 6 | 50 |
| D6*15*50L | 6 | 15 | / | 50 |
| D6*24*75L | 6 | 24 | / | 75 |
| D6*30*100L | 6 | 30 | / | 100 |
| D8*20*60L | 8 | 20 | / | 60 |
| D8*30*75L | 8 | 30 | / | 75 |
| D8*35*100L | 8 | 35 | / | 100 |
| D10*25*75L | 10 | 35 | / | 75 |
| D10*40*100L | 10 | 10 | / | 100 |
| D12*30*75L | 12 | 30 | / | 75 |
| D12*45*100L | 12 | 45 | / | 100 |
| D14*45*100L | 14 | 45 | / | 100 |
| D16*45*100L | 16 | 45 | / | 100 |
| D18*45*100L | 18 | 45 | / | 100 |
| D20*45*100L | 20 | 45 | / | 100 |
| D6*45*150L | 6 | 45 | / | 150 |
| D8*50*150L | 8 | 50 | / | 150 |
| D10*60*150L | 10 | 60 | / | 150 |
| D10*60*151L | 10 | 60 | / | 151 |
| D14*70*150L | 14 | 70 | / | 150 |
| D16*75*150L | 16 | 75 | / | 150 |
| D18*75*150L | 18 | 75 | / | 150 |
| D20*75*150L | 20 | 75 | / | 150 |
