High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit

Discover top-grade Tungsten Carbide Conical Chamfer Buttons for Mining Bit at our factory. Durable, precise, and crafted for superior performance.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Business Type
Manufacturer
Advantage
Over 20 Years Experience in This Line
Transport Package
Customized or Standard
Specification
ISO9001 SGS
Trademark
LIHUA
Origin
Zhuzhou, China (Mainland)
Production Capacity
5000kg/Mon

Product Description

High quality Cemented carbide for coal-mining and iron ore crusher from manufacturer
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
Applications: Application of Tungsten carbide button bits for mining
Tungsten carbide drill bits are widely used in mining, sand,cement,metallurgy and hydropower engineering industries.


High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit


Advantages:
1,Use 100% tungsten carbide raw material
2,ISO 9001 Certification
3,with 23 years experience
4,Advanced technology, automatic pressing, HIP sintering and precision grinding
5,The tolerance of polish (ground) can be done with your request

Tungsten carbide button bits

High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit

High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit


Recommend grade list of tungsten carbide buttons:



Grade

Density
g/cm3

TRS
MPa

Hardness
HRA

Performance & application recommended

YG4C

15.10

1800

90.0

Mainly used as small buttons for percussion bits to cut soft and medium hard formations.

YG6

14.95

1900

90.5

For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring.

YG8

14.80

2200

89.5

For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring.

YK05

14.95

2500

90.5

Mostly used as the buttons of small and medium sized percussion bits and as the inserts of rotary prospecting bits to cut soft and medium hard formations.

YG8C

14.80

2400

88.5

YK15

14.60

2450

87.6

Suitable to strips, conical buttons for rotary percussion-resistant, geological prospection buttons, cut soft and medium hard formations.

YK20

14.40

2500

86.8

Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and hard formations.

YK25

14.40

2550

87.2

Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and very hard formations.

YG11C

14.40

2700

86.5

Largely for the inserts and buttons of percussion bits and tricone bits to cut medium-hard, hard, and very hard formations.

YG13C

14.2

2850

86.0

Primarily for the buttons of tricone bits and inserts of rotary percussion bits to cut hard and very hard formations.

YG15C

14.0

3000

85.5

For oil cone drill bits, for medium soft and medium-hard rocks.


Company Information
About Lihua Cemented Carbide

Established in 1990, specialized in production carbide products more than 20 years and located in the hometown of tungsten carbide in China. We can manufacture all kind of tungsten carbide products.

Our products sold to worldwide . We have built a long term business relationship with the customers from Italy, Portugal, Germany, Turkey, USA, Mexico, Russia, India, Australia and so on.
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit



Main Products

Our Main products include : Carbide Screwed Boring Bar, Plates, Rods, Sticks, Bushings, TP nozzles, 3D Printer Nozzles, Saw Blades, End Mills & Drill Bits, CNC inserts, Value Seats, Rotary Burrs, wheel cutters, Grits, Customized cutter: Woodworking tool cutter, V-cutter, mining tool,  Any customized carbide products are acceptable.
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit

Month capacity of 15Ton

We have sophisticated equipment, such as Sintering Furnace, Automatic suppress Machine, Manual Hydraulic Suppress Machine, Ball Mill Machine, Drying Machine, Mixing Machine etc, Our production capacity up to 15 Ton per month. Customized is welcome, customized sample can be ready in 3-5 days and 1 day can deliver for stocks.

Strictly QC

We have a professional QC team follow to the System of ISO9001:2008, Covering the Raw Materials Incoming, Production Processes, Finished Products and Packaging to ensure high quality products output.

Packing:
In common
Firstly use inner boxes,then to outer boxes or do as customer requested.

High Quality Tungsten Carbide Conical Chamfer Buttons for Mining Bit
