Basic Info.
Model NO.
ZZLGJ-160103
Size
Any Size Accepted Customized
Grade
Yg6,Yg8,Yn8,Yn10,Yg15
Surface
Polished or Unground
Delivery Time
15days
Applications
Cutting Tool
Tolerance
+/-0.05
Product Name
Tungsten Carbide Plate Blanks
Quality
100% G Virgin Materials.
Shipping
DHL,FedEx,TNT,UPS,EMS
MOQ
10 Kg
Transport Package
Carton
Specification
Customized
Trademark
Old Craftsman
Origin
Hunan
HS Code
82090090
Production Capacity
7000kg/Month
Product Description
tungsten carbide plate blanks
1. 100% raw material to produce tungsten carbide products.
2. Hip sintered, high hardness, high wear resistance
3. Various sizes and full types available
4. Reasonable price,Fast delivery time
5. OEM Customized(small order accepted,professional technical support)
6.ISO 9001 Certification
More details of specific type, please inform us
Product information
Size
1.Length: 10.0-500mm, Width: 10.0-500 mm can be accepted
2.High: 1.0-100.0mm
3. Surface: Sintering surface, Ground surface
4. Composition: WC+Co, WC+TiC+TaC+Co
5.Can be designed according to customer's requirements.Grade information
Company Information
Production process
Applications
Tungsten carbide specialized tile plate are used for mineral processing and transportation via mechanical or conveyor systems, such as typical fixed plant equipment consists of chutes, feed bins, fan boxes, crushers, screen plates, fan blades, cyclones and pipe spools.
Small pieces carbide plate mobile plant applications are in high demand in several industries including mining, it is longer life and easier replacement.
Packing and Delivery
Payment terms
RAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 25-35 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<1000USD, 100% in advance. Payment>1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us!
1. 100% raw material to produce tungsten carbide products.
2. Hip sintered, high hardness, high wear resistance
3. Various sizes and full types available
4. Reasonable price,Fast delivery time
5. OEM Customized(small order accepted,professional technical support)
6.ISO 9001 Certification
More details of specific type, please inform us
Product information
Size
| Dimension(mm) | Tolerance | |||
| Unground | Ground | |||
| Height | Length | width | ||
| 100 X 100(1.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 105 X 105(1.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 120 X 120(1.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 150 X 150(10.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 200 X 200(10.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 200 X 100(1.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 200 X 160(1.0~70) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 150 X 120(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 150 X 100(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 100 X 90(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 100 X 80(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 100 X 50(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 100 X 60(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 120 X 50(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| 120 X 80(1.0~40) | +0.5 | ±2.2 | ±2.2 | ±0.01 |
| Notes: We supply the carbide Plates according to the customers' requirements. | ||||
1.Length: 10.0-500mm, Width: 10.0-500 mm can be accepted
2.High: 1.0-100.0mm
3. Surface: Sintering surface, Ground surface
4. Composition: WC+Co, WC+TiC+TaC+Co
5.Can be designed according to customer's requirements.Grade information
| GRADE | ISO CODE | COBALT CONTENT | DENSITY | HARDNESS |
| (%) | g/cm3 | HRA | ||
| K10T | K05-K10 | 4.5-6.0 | 14.95-15.05 | 92.7 |
| YG8 | K30 | 8 | 14.8 | 89.5 |
| YG6 | K20 | 6 | 14.95 | 90.5 |
| YG6X | K10 | 6 | 14.95 | 91.5 |
| YL10.2 | K30 | 10 | 14.5 | 91.8 |
| YG13X | K30-K40 | 13 | 14.3 | 89.5 |
| YG15 | K40 | 15 | 14 | 87.5 |
Production process
Applications
Tungsten carbide specialized tile plate are used for mineral processing and transportation via mechanical or conveyor systems, such as typical fixed plant equipment consists of chutes, feed bins, fan boxes, crushers, screen plates, fan blades, cyclones and pipe spools.
Small pieces carbide plate mobile plant applications are in high demand in several industries including mining, it is longer life and easier replacement.
Packing and Delivery
Payment terms
RAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 25-35 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<1000USD, 100% in advance. Payment>1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us!
