Basic Info.
Model NO.
dia4*310
Material
Tungsten Carbide
Certification
ISO 9001:2008, ISO 9001:2000, GS, CE
Grain Sizes Selection
Ultra Fine, Fine, Medium, Coarse
Surface Finishing
Polished and Unpolished
Main Using Purpose
Carbide Body for Drill Bits/ Endmills / Reamers
Wc+Co Powder
100% Virgin Material
Advantage
Good Quality with Competitive Prices
Transport Package
Safe Exporting Packing
Specification
dia6*330
Trademark
GQ CARBIDE
Origin
Zhuzhou
HS Code
82090090
Production Capacity
2000 Tons Per Year
Product Description
Company Profile
We, GQ CARBIDE TOOLS CO.,LTD, is a professional and with more than 28 years' experience of hardmental products.
Our main products include tungsten carbide rods,strips,plats,disc cutters,etc.
And our carbide are widely used for machining cast iron, steel, stainless steel, aluminum, copper, rubber and so on.
Production Advantage
Large stock of rods
Immediate Delivery
High performance
Grade Introduction
Recommended Applications
Unground Solid Carbide Rods
Unground Cut-Length Solid Rods
PCB Rods
Grade Introduction
Recommended Applications
We, GQ CARBIDE TOOLS CO.,LTD, is a professional and with more than 28 years' experience of hardmental products.
Our main products include tungsten carbide rods,strips,plats,disc cutters,etc.
And our carbide are widely used for machining cast iron, steel, stainless steel, aluminum, copper, rubber and so on.
Production Advantage
Large stock of rods
Immediate Delivery
High performance
Grade Introduction
| Grade | Cobalt content Co% | Density g/cm3 | Hardness HV30 | Hardness HRA | Strength N/mm2 | K1C MPa.m1/2 | Grain size μm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G06A | 6 | 14.9 | 1740 | 92.5 | 3500 | 12 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G15 | 10 | 14.5 | 1600 | 91.5 | 4000 | 11 | 0.8 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G20 | 10 | 14.5 | 1660 | 91.8 | 4000 | 10 | 0.7 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G25 | 12 | 14.2 | 1750 | 92.3 | 4000 | 12 | 0.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G25UF | 12 | 14.2 | 1780 | 92.5 | 4200 | 12 | 0.5 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G30SF | 10 | 14.4 | 1700 | 92.3 | 4200 | 12 | 0.5 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| G35 | 9 | 14.3 | 1960 | 93.7 | 4000 | 10 | 0.3 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recommended Applications
Unground Solid Carbide Rods
Unground Cut-Length Solid Rods
PCB Rods
Grade Introduction
| Grade | Cobalt content Co % | Density g/cm3 | Hardness HV30 | Hardness HRA | Strength N/mm2 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| GSF20A | 6.5 | 14.7 | 2150 | 94.3 | 4000 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| GSF15A | 5 | 14.9 | 2000 | 94 | 4000 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recommended Applications
