Circular Shaped Plate Blank of Tungsten Carbide

Get high-quality tungsten carbide circular shaped plate blanks from our factory. Perfect for industrial applications. Order now for reliable performance.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Grades
Yg8, Yg15, Yg20, Yg10.2, Yg2t, Yg6a
Length
1-320mm
Thickness
Customized
Width
2-200mm
Hardness
65~92.7 Hra
Business Type
Manufacturer
Tolerance
+/-0.01mm
Color
Grey
Surface
Polished
Product Name
Tungsten Carbide Thermocol Plate Making Machine
Transport Package
Carton
Specification
Customized
Trademark
Lihua
Origin
Zhuzhou
HS Code
820900900
Production Capacity
5000 Piece Per Month

Product Description

Circular Shaped Plate Blank of Tungsten Carbide

Circular Shaped Plate Blank of Tungsten Carbide

Product Details

Application

It's often used in Mining, quarrying, ground engineering, etc.

Material       100% raw tungsten carbide
Grade

K05, K10, K20, K30, K40

Design&Size OEM or ODM
Properties High hardness and strength, excellent wear resistance
Finish  Sintered, sandblasting or polish
Packing Our standard packing (paper + carton box or inner box + outer box) or as request
Lead time Sample date: 5-7 working days, mass date: 20-25 working days
Shippment By express( such as DHL, FedEx, TNT, UPS), by air or by sea
Service       We will follow up goods for our customers and help them to solve problems after sales.

Applications

Carbide plate is a highly efficient and green material, which features qualities of stainless steel: Corrosion resistance, oxidation resistance, wear resistance, bonding proof and acid-base resistance; And ensures its good strength, toughness, bending and stretching, impact resistance

Tungsten carbide strip is used for woodworking cast iron  cutting tool. It can be used in many field such as woodworking, machining of refractory alloys, stainless steel, high manganese steel, for processing cast iron, non-ferrous metal and aluminum section bar, etc

Advantage

1.Superior heat stability.
2.Anti-deformation in high temperature.
3.Fine thermal shock resistance.
4.High thermal conductivity.

5.Excellent Oxidation control ability.
6.Strong anti-corrosion in high temperature.
7.Good corrosion resistance from Chemical.
8.High-wearing feature.
9.Long usage lifetime.

Circular Shaped Plate Blank of Tungsten Carbide
Grade Recommend

The grades which used more frequently are YG8, YG15, YG20, YG10.2, YG2T, YG10X etc.

Other grades can be offered according to customers' requirements. Afterwards the board can be broken out from the panel.


GRADE

ISO CODE

COBALT CONTENT

DENSITY

HARDNESS

TRS

(%)

g/cm3

HRA

N/mm2

K10T

K05-K10

4.5-6.0

14.95-15.05

92.7

1800

YG8

K30

8

14.80

89.5

2200

YG6

K20

6

14.95

90.5

1900

YG6X

K10

6

14.95

91.5

1800

YL10.2

K30

10

14.50

91.8

2400

YG13X

K30-K40

13

14.30

89.5

2600

YG15

K40

15

14.00

87.5

2800

YL20.8

K40

15

14.00

88.5

3800



Circular Shaped Plate Blank of Tungsten Carbide


                                                                           Unit: mm

TYPE

TOL

Blank

Polished

H

W

L

100×100(1.0~70)

+0.5

±2.2

±2.2

±0.01

105×105(1.0~70)

+0.5

±2.2

±2.2

±0.01

150×150(5.0~70)

+0.5

±2.2

±2.2

±0.01

200×200(5.0~70)

+0.5

±2.2

±2.2

±0.01

200×100(1.0~70)

+0.5

±2.2

±2.2

±0.01

320×200(1.0~70)

+0.5

±2.2

±2.2

±0.01

120×120(1.0~70)

+0.5

±2.2

±2.2

±0.01

150×120(1.0~40)

+0.5

±2.2

±2.2

±0.01

170×80×(1.0~20)

+0.5

±2.2

±2.2

±0.01

150×100(1.0~40)

+0.5

±2.2

±2.2

±0.01

100×90(1.0~40)

+0.5

±2.2

±2.2

±0.01

100×80(1.0~40)

+0.5

±2.2

±2.2

±0.01

100×50(1.0~40)

+0.5

±2.2

±2.2

±0.01

100×60(1.0~40)

+0.5

±2.2

±2.2

±0.01


Company Introuduction

1) Business Type:  Manufacturer, Factory.

    ISO9001:2008, SGS.

    Focus on Cemented Carbide Industry for more than 20 years.

2) Advanced technology, HIP sintering and precision grinding to ensure the goods performance;

3) 100% Virgin pure Raw materials;

4) Each product through the strict inspections and confirm to the requirements of the lab parameters;

5) OEM & ODM are welcomed;

6) Small order is acceptable;

7) Flexible payment terms (L/C,T/T, western union, etc);

8) Provide custom made service with customer's drawing; Other size could be offered by your requirements;

9) We make sure to provide you with the best solutions for your individual case. Whether standard items or non- standard items all available;

10) Fast delivery and high quality;

11) Best after-sale service.

About Lihua Cemented Carbide
Circular Shaped Plate Blank of Tungsten Carbide
Established in 1996, specialized in production carbide products more than 20 years and located in zhuzhou city  which is the hometown of tungsten carbide in China .
Our products sold well to worldwide, has been build a long term relationship with our customers from Italy, Portugal, German, Turkey, USA, Mexico, India, Australia, South Africa etc .

Main Products
Our Main products include : Carbide Screwed Boring Bar, Plates, Rods, Sticks, Bushings, TP nozzles, 3D Printer Nozzles, Saw Blades, End Mills & Drill Bits, CNC inserts, Value Seats, Rotary Burrs, wheel cutters, Grits, Cusomized cutter:woodworking tool, V-cutter, textile cutter, shoes cutter ects. Any kinds of customized carbide products .

Monthly Capacity of 15 Tons
We have sophisticated equipments, such as Sintering Furnace, Automatic suppress Machine, Manual Hydraulic Suppress Machine, Ball Mill Machine, Drying Machine, Mixing Machine ect, Our production capacity up to 15 Tons per month. Customized is welcome, customized sample can be ready in 3-5 days and 1 day can deliver for stocks.

Strictly QC
We have a professional QC team follow to the System of ISO9001:2008, Covering the Raw Materials Incoming, Production Processes, Finished Products and Packaging to ensure high quality products output.


Main Products


Circular Shaped Plate Blank of Tungsten Carbide









Packing:
In common
Firstly use inner boxes,then to outer boxes or do as customer requested.


Shipping Methods:
Shipment methods: By air or sea,DHL,UPS,FEDEX,TNT or as your resquest.
DHL: 10-14 working days
FedEx: 7 to 10 working days
UPS: 7 to 10 working days
EMS: 10-14 working days
If there is any problem, please feel free to contact us. We are pleased to be on service of you in near future.



Circular Shaped Plate Blank of Tungsten Carbide



Payment:

Less than or equal to $1000: 100% advance via Paypal ,or Western Union

Over $1000: 30% T/T advance , Balance before shipment .
