Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold

Get high-quality Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold from our factory. Perfect for wire drawing applications.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
RONEN Dies
Shaping Mode
Die Casting
Hole Type
Depends on Different Requests
Cavity
Depends on Different Requests
Surface Treatment
Polish
Application
Hardware, Home Use, Commodity, Car
Certification
CE
Warranty
1 Year
Customized
Customized
Product Name
Wire Drawing Die
Shaping
Die Casting, Drawing Die
Product
Vehicle Mould
Product Material
Metal
Keywords
Artificial Diamond Drawing Forming Dies Mold
Model Number
Customized
Delivery Time
Delivery on Time, Without Delay
After Sales Service
Provide Solutions Within 24 Hours
Price
Factory Direct Supply Price
Tolerance
+_0.04 mm
Drawing Dies Diameter
0.01mm-50mm
Supply Ability
50000 Sets Per Month
Package
Export Packing
Application Range
Drawing Dies
Custom Products
Provide
Transport Package
Wooden Case or as You Want
Specification
Customized
Trademark
RONEN
Origin
Hebei, China
Production Capacity
10000PCS/Year

Packaging & Delivery

Package Size
10.00cm * 10.00cm * 20.00cm
Package Gross Weight
0.500kg

Product Description

Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold

Company Introduction
Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold Technique Parameter
Model Type
Fetures
Range of application
Artificial monocrystalline die
Natural diamond, good retentivity of hole roundness and stable quality
0.01mm-0.70mm
fine wires
Various shaped artificial diamond dies
Good finish, high precision and strong wear resistance
Gold & silver jewelery, copper wires, zipper flat wires, tooth flat wires, square CP wires, stainless steel shaped wires and other shaped wires
Natural diamond drawing die
High-precision wire drawing industry and its correct hole
0.01mm-1 .5mm
various fine metal wires
Nano drawing die
Forming a CVD diamond coating on the surface of tungsten carbide die
Strand wire and the drawing of nonferrous metal like copper, aluminum atc.
Artificial polycrystalline drawing die
Long service life, more repair times and wide range
0. 1mm-12.00mm
Round carbide drawing die
High wear resistance and high thermal conductivity
0. 15mm-50mm
Drawing of various metal wires, tubings and rods.
Various shaped carbide dies
With high-quality cemented carbide as the raw material
Drawing, reducing, scalping and extrusion of copper, alumium, iron, stainless stell, aluminum alloy and other metal wires,tubings and rods
Standard Tolerance Corresponding To Diameter
Diameter(mm)
Tolerance(mm)
Maximum out-of-roundness(mm)
<0.020
+0 -1.5%
0.5%
>0.020~0.025
+0 -0.0003%
0.0002
>0.025~0.050
+0 -0.0004%
0.0003
>0.050-0.075
+0 -0.0006%
0.0004
>0.075~0.100
+0 -0.0008%
0.0004
>0.100~0.200
+0 -0.001%
0.001
>0.200~0.500
+0 -0.002%
0.0015
>0.500~1.000
+0 -0.003%
0.002
>1.000-2.000
+0 -0.004%
0.0025
>2.000~3.500
+0 -0.005%
0.003
>3.500~5.500
+0 -0.006%
0.0035
>5.500~8.000
+0 -0.007%
0.004
>8.000~10.000
+0 -0.008%
0.0045
>10.000~12.000
+0 -0.010%
0.005
>12.000~15.000
+0 -0.012%
0.006
>15.000~18.000
+0 -0.014%
0.007
>18.000~21.000
+0 -0.016%
0.008
>21.000~24.000
+0 -0.018%
0.009
>24.000~30.000
+0 -0.020%
0.010

Ronen Group Is committed to designing and manufacturing of induction heating equipment, which are widely used in Machinery, Building Materials,Metallurgy, Paper Making, Automobile Manufacturing and other fields, to fully meet the needs of Steel Pipe Seam Welding,Stainless Steel Pipe Welding, Strip Heating, Vacuum Melting, Copper Pipe Welding, Steel Pipe Annealing, Refrigerator Tube Welding,Metal Heat Treatment, Metal Smelting, Welding, Brazing, Thermal Assembly and other Induction Heating Process Requirements, mainly include Spring Steel Wires, High-Strength Pipe Piles PC Steel Rods / PC Bar, Prestressed Steel Wire, Prestressed Concrete Strand, Rebar, Aluminum-Plastic Pipes, Wires and Cables Production Equipment lines.

Ronen Group Domestic market share is more than 60%, and In recent years, we have exported our machines to USA, Europe, Russia, Egypt, Japan, Korea etc. more than 25 countries.

Ronen will always be here for you!

Product Description

Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold
Artificial Monocrystalline die

Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold
Tinned die series
Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold
Drawing Dies
Application
We mainly provide service for processing plants of stainless steel wire, tungsten molybdenum filament, gold wire, silicon aluminum wire, super-fine enamelled wire and super-fine noble metal wire. The thread throwing dies have a major product size from 0.01mm to 50mm (diameter) or the size based on the technical standard offered by the customer and we can keep a punctual delivery and contractual promise.
Our service tenet is that customer' s satisfaction is our target. We sincerely wish to establish a bright and successful future together with partners around the world.

Ronen Group Workshop Show

Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold

Ronen Group Exhibition

Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold
Certifications
Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold

Packing and Shipping

Long Life Natural Diamond Tungsten Carbide Cemented Wire Drawing Dies Mold

FAQ:

Q: Are you manufacturer?
A:Yes, We are manufacturer.
Q: How to order?
A:Please send us your inquiry by email, send message through Alibaba , Wechat, Whatsapp or others as you want.
Q: What are the payment terms?
A: Pattern :we can accept L/C,T/T,Western Union ,Money Gram.
Q: What is the whole business flow cooperation with us?
A: 1.Firstly,send your inquiry to us, make us have learned your requirement
2.We will be drawing a proforma invoice according to your requirement ,and start production after you finished to pay 30% deposit.
3.All of the goods, packing details, and B/L copy will be send to buyer after finished production. We will
arrange shipment and provide original B/L after the buyer finished to pay the balance.


Not only the Good Machine, but also the Most Attentive Service
If any doubt,feel free to contact us with no doubt!
RONEN always here for you!!
