Cemented Carbide Tipped Circular Saw Blade for Cutting

Get high-quality Cemented Carbide Tipped Circular Saw Blades for Cutting from our factory. Precision-engineered for maximum durability and performance.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Condition
New
Material
100%Tungsten Carbide(Wc+Co)
Processing
Laser Welding
Finishing
Painted&Polished
Advantage
High Efficiency
Tooth Type
Aternating Teeth/Ladder Flat Type
Teeth Number
40t/60t/80t/100t/120t
Angle
25° 30° 35° 40°
Quality Grade
Cold Press Sintered Blade
Shape and Type
According on Your Requirements
Color
Grey
Transport Package
Carton
Trademark
Lihua
Origin
Zhuzhou
HS Code
8202310000
Production Capacity
50000 Piece Per Month

Product Description

Cemented Carbide Tipped Circular Saw Blade for Cutting

Cemented Carbide Tipped Circular Saw Blade for Cutting

Tungsten carbide blade is widely used in many industrial fields in our coutry . It is of stable property and mature technology and applies to more circles. The blades our produces are as follow:

1, Tungsten carbide index-able blade

2, Tungsten carbide welding blade

3, Special carbide blade for paper-making industry, wood-cutting industry, metal industry , etc.

Cemented Carbide Tipped Circular Saw Blade for Cutting

Advantages:

1. Located in Zhuzhou - the fifth biggest cemented carbide base in the world;

2. Professional manufacturer for tungsten carbide items with more than 20 years experience;

3. Advanced production equipments and testing equipments;

4. With strict quality control system: material incoming test-first samples test--production test-outgoing goods test etc;  (hardness/ magnetic saturation/ density etc.)

5. Standard and non-standard are all supported.



All products with

  •   ISO 9001-2008 Quality Control System ;
  •   100% virgin tungsten carbide ;
  •   OEM,ODM project accepted ;
  •   All payment terms supported ;
  •   Fast delivery time & Convenient Transportation .


Teeth Form

Metal Circular Saw Blade are Ground . According to Different Kinds of Application. With Different Kinds of Teeth Form.

Tooth Form "A"

For thin Metal slitting saw blade with a tooth pitch up to approx 3.0mmAdvisable for Brass.

Tooth From "B" Suitable for cutting tubes and profile made of steel or metal
Tooth From HZ A tooth pair is consisting of one roughing tooth (1/3 cutting width) and one finishing tooth (2X1/3 cutting width)

Cemented Carbide Tipped Circular Saw Blade for Cutting

Exterior Coating

Special Oxidation - VAPO

It produces a layer of iron oxide on the surface, which increases the wear-resisting and increases the overall life. Suitable for general cutting work .



Titanium Nitrider Coating - TiN

This is an excellent PVD coating for protecting saw blade form wear, which is a good choice for iron based material and cutting conditions requiring resistance to both abrasive and adhesive wear.



Titanium Aluminum Nitride Coating - TIALN

TIALN is a new multi-layer wear protection PVD coating . Recommended for high tension strength materials above 800N/mm^2 and stainless steel. Responds very favourably to high speed and feed rates well as extreme working conditions like dry cutting.



Titanium Carbonit Nide Coating - TICN

TICN is a "high performance" PVD Coating suitable for severe abrasive wear cutting conditions. Recommended for high tensile strength materials above 800N/mm^2 and stainless steel. Especially for cutting the material in high speed and feed rate. Coating thickness 0.003mm.

Company Informations
Cemented Carbide Tipped Circular Saw Blade for Cutting

About Lihua Cemented Carbide

Established in 1996, specialized in production carbide products more than 20 years and located in the hometown of tungsten carbide in China. We can manufacture all kind of tungsten carbide products.

Our products sold to worldwide . We have built a long term business relationship with the customers from Italy, Portugal, Germany, Turkey, USA, Mexico, Russia, India, Australia and so on.

Main Products

Our Main products include : Carbide Screwed Boring Bar, Plates, Rods, Sticks, Bushings, TP nozzles, 3D Printer Nozzles, Saw Blades, End Mills & Drill Bits, CNC inserts, Value Seats, Rotary Burrs, wheel cutters, Grits, Customized cutter: Woodworking tool cutter, V-cutter, mining tool,  Any customized carbide products are acceptable.

Month capacity of 15 Tons

We have sophisticated equipment, such as Sintering Furnace, Automatic suppress Machine, Manual Hydraulic Suppress Machine, Ball Mill Machine, Drying Machine, Mixing Machine etc, Our production capacity up to 15 Tons per month. Customized is welcome, customized sample can be ready in 3-5 days and 1 day can deliver for stocks.

Strictly QC

We have a professional QC team follow to the System of ISO 9001:2008, Covering the Raw Materials Incoming, Production Processes, Finished Products and Packaging to ensure high quality products output.
Cemented Carbide Tipped Circular Saw Blade for Cutting

Other Products
Cemented Carbide Tipped Circular Saw Blade for Cutting

Packing:
1. First packed in plastic boxes sperately
2. Then in paper box, the type can be seen from the special designed part
3. Last in cartons for final shipment



Shipping Methods

By air or sea,DHL,UPS,FEDEX,TNT or as your resquest.
Below shows the estimate delivery time for different courier:
DHL: 10-14 working days
FedEx: 7 to 10 working days
UPS: 7 to 10 working days
EMS: 10-14 working days

Cemented Carbide Tipped Circular Saw Blade for Cutting
