OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves

OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves - Quality products from a trusted factory. Explore our wide range of options for your control valve needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Zonco-11447
OEM
Available
Temperature
High Temperature
Transport Package
Carton or Wooden Case. Also Can Be Customized as P
Specification
Customization
Trademark
ZONCO
Origin
China Zhuzhou
HS Code
84819000
Production Capacity
800-1000PCS Per Month

Product Description




OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves

OEM Tungsten carbide trims and seat carbide plug head used in control valves


1. 100% virgin raw materials.
2. Various kinds of grades are availalbe based on customer's application.
3. we have professional advanced production line and inspeciton equipments to ensure high quality products.
4. Precision Ground and high polishing process
5. High wear resistance,high hardness and impact toughness
6. Advanced technology , precise grinding.


Common Alloy Grades, Ghysical Mechanical Properties And Recommended Application
Grade WC% Co/Ni % Physical and mechanical properties Grain size (μm) Recommended application
Density (g/cm3) TRS (N/mm2) Hardness (HRA)
ZG01 100 0 15.3-15.5 1200 95.5 0.3 Ultra-high hardness, high wear resistance, anti-corrosion, with certain anti-destructive ability
ZG04X 96 4 15.0-15.2 1600 92.8 0.8-1.0 Suitable for drawing die, non-ferrous metal wire drawing and wear-resistant parts
ZG06 94 6 14.8-15.1 2500 90.0 1.2 Good abrasion resistance, good compression resistance, suitable for wear-resistant parts that resist abrasion and high pressure.
ZG06X 94 6 14.8-15.1 2400 91.5 1.0 Superio wear resistance,good comprehensive properties,suitable for making non-standard structure components with higher wear resistance.
ZG06A 94 6 14.8-15.1 2150 92.5 0.6-0.8
ZG08 92 8 14.6-14.9 2700 89.0 1.2-1.6 Good general performance, used for general wear parts, molds, general tools, etc.
ZG10.2 90 10 14.3-14.6 3800 91.7 0.7 Good general performance, suitable for casing and oil nozzle products
ZG11 89 11 14.3-14.7 2800 88.5 1.2-1.6 Anti-wear, anti-erosion, good comprehensive mechanical strength, suitable for wear-resistant parts in the petroleum, chemical and mechanical industries.
ZG12X 88 12 14.2-14.5 3000 89.5 1.0-1.2 Anti-erosion, good comprehensive mechanical strength, suitable for impact-resistant wear-resistant parts, molds, and roller rings.
ZG15 85 15 13.8-14.2 3000 86.5 1.2-1.6
ZG15X 85 15 13.8-14.2 4500 89.0 0.7 Excellent wear resistance and toughness,it is suitable for making integral stamping dies, anti-vibration toolholders, etc.
ZG20 80 20 13.4-13.8 3100 85.0 1.0 Excellent wear resistance and toughness
ZN06 94 6 14.5-14.9 2000 90.0 1.2 Non-magnetic alloy, suitable for sealing ring, non-magnetic wear-resistant parts and corrosion-resistant parts.
ZN09 91 9 14.3-14.6 2300 89.0 1.2-1.6
ZN11 89 11 14.0-14.3 2600 88.0 1.2

OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves
OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves
OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves

OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves
OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves





OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves

Material: Carbide woodworking machine clamp blade, spiral blade manufacturer, using micron-level granular raw materials, low-pressure sintering, ensuring high wear resistance and high bending strength of the product, using CNC and special equipment to create high-quality products through 23 procedures. The large surface is mirror-polished, and the cutting edge has undergone 3 times of differential treatment, and there is no wave under a 100x magnifying glass, which prolongs the use time of the product. Provide customers with solutions for processing different materials.

Applicable equipment: Woodworking turning tool, double-sided planer, four-sided planer, vertical shaft machine
Processing range: solid wood, plywood, dense version, acrylic, plastic, etc.

Our cutters are strictly inspected after each process, including body thickness, size, flatness, bore, angle, joint length,
hardness and etc. We promise to ship 100% qualified product.


Advanced Testing instruments
1.Cobalt Magnetic Analyzer
2.Nonferrous Metal Analyzer
3.Coercive Force Automatic Measuring Instrument
4.Carbon Detector
5.3D Projectors
6.Metallography Image Analyzer
7.Full Digital Ultrasonic Flaw Detector etc.


OEM Tungsten Carbide Trims and Seat Carbide Plug Head Used in Control Valves


Our Services
Before transaction
We give you warm responses in 8 hours.
We will answer once we see your messages.
And our product's quality is wonderful in Chinese suppliers.



After transaction

We continue to follow up the order's progress.

Produce fast &  Delivery  fast

We are not only buyer-seller relationship but also friend relationship



FAQ:




Q: Is Zonco trading company or manufacturer ?

A: Zhuzhou Zonco Industial Co.Ltd is a manufactuer of tungsten carbide and diamond abrasives since established on 1998,specializing in carbide plates/bushings/rollers/special wear parts and various diamond grinding wheels.




Q: Has Zonco acquired the formost certification of ISO 9001?

A: Zonco has been endorsed with the ISO 9001 rating since 2008.




Q: When can I get the offer after sending inquiry?

A:We usually quote within 24 hours after we get your inquiry .If you are very urgent to get the price please call us or tell us in your email so that we will regard your inquiry priority.




Q: Could Zonco  sales staff be reached anytime for assistance regarding orders or general enquiries ?

A:Our sales staff oprates between 8am-6pm Monday to Saturday.

Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
