Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted

Shop our high-quality U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness. Custom orders welcome. Factory direct. Order now!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Specification
  • Production Site
  • Packaging
  • Reviews From Customers
  • Company Profile
  • Company Advantage
  • FAQ
Overview

Basic Info.

Grade
Mc15
Compositions
Wc: 85%, Binder Co+Ni: 15%
Density
14.05g/Cm³
Hardness
HRC68-78
Features
Resistant to Wear Corrosion and Impact
Applications (Hot Rolling)
Rod Mill Guide Roller, Forming/Reducing/Pinch Roll
Transport Package
Standard Export Carton
Specification
Custom Service Available
Trademark
Miller ™
Origin
Zhuzhou, China

Product Description

Product Description


Guide roller is an indispensable device which is installed before and after the hot wire rolling pass to help the rolled piece enter and export the roll pass accurately and stably according to the given direction and state in the rolling process of section steel.

Compared to steel, tungsten carbide is a much more better choice for guide roller due to its high rigidity, good wear resistance (the service life is matched with the high-quality bearing), good thermal conductivity, a certain of red hardness. And the life of WC rollers is typically more than 10 times longer than steel rollers.


Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted

Product Specification

  Availbable Guider Roller Types

Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted

Flat Type Double Flanged Single Flanged With Trapezoid Groove   With R Groove  V Groove    Tapered Type
Please consult our engineer for professional advice on the detailed types and specs of rollers if needed.


Miller MC15 the hardness is a "built-in" characteristic and not the result of processes like heat-treatment, plating or nitriding. In this case the product is a true hard-metal in which a hardness of approximately 86HRA (approx. 70HRC) is reached by sintering. They are non-magnetic, non-heat treatable and cannot be turned by lathe, but must be grounded by diamond wheels.


Material Material

Miller MT10

T.C

Tool Steel

Binder

Alloy Steel

Co-Ni

Fe

Hard Phase

TiC

WC

Fe3C

Manufacturing Process

Powder Metallurgy

Powder Metallurgy

Casting

Hardness (HRC) Tempered

68-70

68-78

55-62

Hardness (HRC) Annealed

45-48

68-78

20-30

Density(g/cm³)

6.45-6.60

14.0-15.0

7.8-8.5

Bend Strength(N/mm2)

1650-1850

1950-2300

580-1000

Compressive Strength(N/mm2)

3500-3800

3200-4300

2000-2700


Production Site

Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted



Packaging

Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted


Reviews From Customers

Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted


Company Profile

Miller Carbide is an experienced manufacturer of tungsten carbide customized parts started from 2008. Our products cover carbide grinding jars & mortars, carbide grinding balls, carbide pegs, carbide static & dynamic rings, bead mill disks, carbide stirring rods, carbide static & dynamic jaws, carbide crusher plates, carbide grinding discs, carbide rotors, carbide roll rings, carbide guide rolls, carbide burrs, carbide sleeves & bushings, and other customized wear-resistant components for valve and pumps ect. With years of tungsten carbide engineering and manufacturing experience, we can concentrate our skills to the development of customized products for a wide spread of wear applications in milling & crushing industry.

Unlike other suppliers, Miller operates with three disciplines: Engineering, manufacturing and after sale service support. This means we are able to improve the efficiency of your machine and tools with customized products and direct access to the manufacturer. Miller Carbide works closely with its customers to ensure their requirements are designed efficiently and suitable for application. We can design the components needed from drawings or delivered samples.

We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. We are sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with an irresistible force.

Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted Source Factory U-Groove Bearing Pulley Tungsten Steel Roller with High Hardness Non-Standard Accepted


Company Advantage


We Offer You These

 Direct Sales
Integrating R&D, production
  sales and technology
Mold customization
Rich molds

OEM customization accepted
Adequate equipment
grinding/pressing
sintering/deep processing
Technical strength
15 years of experience in

 technical team, research & innovation


FAQ


1. How long is your delivery time?
We can arrange the shipment within 3-5 working days upon receipt of your payment for any sintered blanks stocked items. As for the mass production order or the customized products, we will need 10-30 days production leadtime and indicate the delivery time on the Proforma lnvoice.

2. Can l get a sample from you for Quality checking? Is it free of charge or need pay ?
Yes, we can offer the sample for free of charge with freight collected if we have in stock.
If the sample is special or non-standard shaped, we will charge you only the basic production costs accordingly.

3. What's grade should I choose for the product?
If you have no idea about the grade, please kind to provide the information of the usage of the product, our technical team will suggest the most suitable grade for you.

4. Do you use recycle materials?
We insist on quality come first, all the products are made of virgin raw materials.

5. Can you make the goods according to my sample or drawing ? What's your (MOQ) minimum order quantity?
Yes, We have a group of experienced technical personnel, advanced mould production equipments. Our R&D teams were graduated from University, and our technical R&D team lead by Doctors of Powder Metallurgy and Professors.
For the customized item we quote the MOQ individual; For the standard items in stock, we have no limitation on the MOQ .

6. Can I negotiate the Prices?
Yes, we can consider the discount for bulk orders.

7. Can you give warranty of your products?
Yes, we can give you 100% satisfaction guarantee on all items. We have the independent inspection department with the complete  advanced product quality testing instrumentation to carry out IQC, PQC, FOC, and the detailed inspection pictures and testing report will be available and sent to you for confirmation before delivery.
In case there was any quality problem, just please kindly to provide the pictures to show the problem by email. We should be 100% responsible for our problems and provide you the replacements at our costs.
